AMPLIROLL^® LOW PROFILE - 24T CAPACITY

TECHNICAL DATA

For GVW from 26 T	MINI (mm)	MAXI (mm)	RUP (mm)	H (mm)	Weight (Kg)
S49	4500	6100	5100	195	2278
S51	4500	6300	5300	195	2298
S52	4600	6400	5400	195	2350
S53	4700	6500	5500	195	2365
S55	4900	6700	5700	195	2425
S56	5000	6800	5800	195	2477
S57	5100	6900	5900	195	2492
S58	5100	7000	6000	195	2530
S59	5200	7100	6100	195	2550
S61	5200	7300	6300	195	2580

ARGUMENTS

• Power: unique tilting frame and boosters system to provide unmatched lifting capacity
• Productivity: bigger available space
• Convenience: DANFOSS hydraulics solution with premium controls
• Robustness: high quality strength steels
• Versatility: lengths from 49 to 61

HIGHLIGHTS

• Hooklift's height optimized
• Marrel manufactured cylinders
• Integrated safety to prevent miss-use
• Removable hook or with safety latch
• Customization possibilities

OPTIONS

• Radiocommande
• Hydraulics front lock
• Panto rear underrun protection adjustable or fixed
• Crane base subframe prolongation
• Hydraulic boxes and oiltank
• Hooks selection: heights and types
• Fixation kits depending on the truck chassis
