AMPLIROLL^® LOW PROFILE TELESCOPIC AND ARTICULATED JIB - 22T CAPACITY

TECHNICAL DATA

For GVW from 26 T	MINI (mm)	MAXI (mm)	RUP (mm)	H (mm)	Weight (Kg)
S49	3800	6100	5100	195	2167
S51	4000	6300	5300	195	2387
S52	4500	6400	5400	195	2434
S53	4200	6500	5500	195	2449
S55	4300	6700	5700	195	2500
S56	4400	6800	5800	195	2548
S57	4500	6900	5900	195	2563
S58	4600	7000	6000	195	2600
S59	4700	7100	6100	195	2620
S61	4900	7300	6300	195	2650

ARGUMENTS

• Power: unique tilting frame and boosters system to provide unmatched lifting capacity
• Productivity: bigger available space
• Convenience: DANFOSS hydraulics solution with premium controls
• Robustness: high quality strength steels
• Versatility: lengths from 49 to 61

HIGHLIGHTS

• Hooklift's height optimized
• Marrel manufactured cylinders
• Integrated safety to prevent miss-use
• Removable hook or with safety latch
• Customization possibilities

OPTIONS

• Radiocommande
• Hydraulics front lock
• Panto rear underrun protection adjustable or fixed
• Crane base subframe prolongation
• Hydraulic boxes and oiltank
• Hooks selection: heights and types
• Fixation kits depending on the truck chassis
